Textek A3 A4 Sheet 30cm Roll Dtf Printer Dtf Film Printer Dtf Heat Transfer Machine
We will offer a commercial DTF printer system that prints onto a 300mm or 600mm wide roll. Because of the durability enhanced by the special ink and adhesive, DTF printing is ideal for work and sport wear. The print doesn’t crack like screen printing as it has a very soft hand due to the water-based ink used.
Textek A3 A4 Sheet 30cm Roll Dtf Printer Dtf Film Printer Dtf Heat Transfer Machine
Textek hot selling new technology PET film heat printing machine from Zhengzhou Textek
The whole set has two machines: one is a PET film inkjet printing machine with CMYK+W heat transfer pigment ink, one is powder shaking and dry machine. The first step is print CMYK+W ink to pet film. The second step is to put the hot melt powder to printed film and shaking powder, the dryer the film and picture. Then the printed film be finished. After the above two step, heat transfer picture to the garment, bag, leather and so on. Many fabric materials suitable for this printing process. No limited fabric of this printing, easy to operate.
| Printer Head | XP600 2PCS |
| Production Speed and accuracy | 6 pass:4.5sqm/h 8 pass:3.5sqm/h |
| Main Board | Honson |
| Ink | water-based DTF ink; CMYK+WHITE（2 fluo colors are optional） |
| Color Manage | ICC or density curve |
| Print Media | PET Film |
| Print Width | 300mm |
| RIP Soft | Main Top |
| Operate system | Windows xp win7 or above |
| Power | 50HZ/60HZ,220V/110V 10A |
| Document Format | BMP/TIF/JPG/EPS/PDF |
Machines Features:
1.Printing width: for 30cm pet film
2.Double print heads XP600, fast printing production for White and Color Ink output at the one pass
3.The printing speed is 3-4 m2/h
4.With Famous Honson board stable for XP600 printer system
5.With White ink pump motor stirring system, prevent white ink from clogging
6.Railway guide—Taiwan HIWin railway guide, use aluminum material ,the whole guide rail is mute and integrated
7.Motor: Use Jiemeikang servo motor, high precision, not easy to lose step
8.With Materials Automatic feeding and take-up system, easier for roll to roll pet film printing
Machines Details:
